F4U Corsair 'Camo Big Hog' 71in Wingspan ARF

Additional Images:

  Click On Images to Enlarge

Overview

The Vought F4U Corsair is an American fighter aircraft that saw service primarily in World War II and the Korean War . Designed and initially manufactured by Chance Vought, the Corsair was soon in great demand The Corsair was designed and principally operated as a carrier-based aircraft , and entered service in large numbers with the U.S. Navy and Marines in World War II. It quickly became one of the most capable carrier-based fighter-bombers of the war. Some Japanese pilots regarded it as the most formidable American fighter and U.S. naval aviators achieved an 11:1 kill ratio.

VQ Model introduces the F4U Corsair in the most popular size (120 size). You have a lot of power options, from nitro 2-stroke 120, nitro 4-stroke 125-150 (Saito FA-125A/FA-150B), gas 21-25 cc, electric motor and even fit with Saito FG-33R3 Radial engine. With lots of scale details like the WWII US Navy Pilot, Rocket, Subtank... make your F4U Corsair the most scale warbird on your flying field.

Specifications:

Wingspan:	1810mm (71in)
Fuselage Length:	1390mm (54.7in)
Weight:	6.3 - 6.7kg
Nitro Engine required (Not Supplied):	120 (2 stroke) or 125-150 (4 stroke)
Gas Engine required (Not Supplied):	20-26cc (2 stroke) or 21-30cc (4 stroke) | Radial Engine - Saito FG-33R3 or FA-200R3
Electric Motor (Not Supplied):	TBC
Battery (Not Supplied):	Lipo 6S 6000 mAh
Propeller (Not Supplied):	17 x 6 - 19 x 6
Radio required (Not Supplied):	9 channels with 12 servos - Standard servo (2 x Aileron, 2 x Elevator, 1 x Rudder) | Mini Servo (4 x Flaps, 2 x Main Gear Door, 1 x Throttle)

Features:

• All balsa and lite-ply construction
• Fibreglass cowling
• Control surfaces pre-hinged and installed
• Fully covered in weathered detail
• Scale Navy Pilot
• 3D printed Rocket
• All main gear door operation

Includes:

• Assembly instructions - [ Download ]
• Gear assembly
• Wheels
• Engine mounts
• Fuel tank
• Fibreglass cowling
• Aluminium wing joiner
• Decals and all hardware
• Optional:95 Degree Aluminium Rotating Electric Retracts with Scale struts (VQARE34)

Does not include: radio, motor, glue, and silicon fuel line

Recommended Hardware (Not Supplied):

• Servos: 5 x MG5510DS 9.98Kg.cm/0.12s Standard Size Digital Servo and 7 x MG1703DS 3.3Kg.cm/0.10s Mini Digital Servo
• Engine: DLE20 2-Stroke Petrol Engine | Saito FA-125A 4-Stroke Glow/Nitro Engine | Saito FG-21 4-Stroke Petrol Engine
• Radial Engine: Saito FA-200R3 4-Stroke Glow/Nitro Engine | Saito FG-33R3 4-Stroke Petrol Engine
